UBDHB350 2R

Declaration of conformity

Hollow space floor box double, round

Hollow space floor box consisting of a Sendzimir hot-dip galvanized sheet steel box with all-round bendable side walls including grounding clamp for a subsonic noise free and height independent assembly. Usable as pull- and installation box, with one opening for insertion of a shuttering tube that will be replaced with a round plastic or high-grade steel assembly unit during final assembly.

Continously hot galvanized (Sendzimir process) (DIN EN 10346)

Name H[mm] Hmin [mm] B1[mm] B2[mm] L1[mm] L2[mm] E[mm] G[kg]
UBDHB350 28-259R
31
63
410
450
410
450
260
3,8
+
UBDHB350 38-259R
41
73
410
450
410
450
260
3,9
+
UBDHB350 48-259R
51
83
410
450
410
450
260
4
+
